MOTORIZED
INTERIOR SHADE

• Available in width of 28″ up to 168″ measured bracket to bracket with coupled shade applications and angled couplers for single motor operation of larger expanses.
• Available in drops of 12″ up to 192″ with total drop measured from top of bracket to bottom of hem bar
• Minimum split (1/4″) coupled shades.
• 5.5″ head box with concealer plate available for recessed applications
• Black out track and 4″ or 5″ fascia in standard colors: white, tan, black, bronze or anodized aluminum
• Powder-coated steel brackets available in standard colors: white, tan, black, bronze or anodized aluminum
• Adjustable leveling brackets
• Retractable idler end
• Precision idle bearing
• Motorized by Somfy motors, the premier motor in the industry including wide range of Standard, Altus RTS, Sonesse RTS, Sonesse ILT & ILT motors with complete integration into automation systems
• Extensive selection of standard roll off back fabrics or “waterfall” roll off front applications
• Welded (not sewn) fabric seams in horizontal application for solar fabrics and either horizontal or vertical application for acrylic fabrics
• Seam placement comes standard at highest possible height or at customer specified height as measured from bottom of hem bar
• Roller tubes are 60/61 T6 aluminum alloy, available in 63mm, 70mm and 78mm steel.
• Manufacturing deductions taken during production
  • Fascia – 0″
  • Roller tube – 1 7/8″
  • Weight bar – 3 ½”
  • Fabric – 2″
  • Hem bar – 2″
• Limited Lifetime Warranty
